Humerus
A Game
Skeleton for Albow
Version 2.1
Contents
Introduction
Humerus is a set of classes for use with the Albow widget library. It
provides an infrastructure and basic user interface for a game, with
optional support for progression through a sequence of levels and a
built-in level
editor.
Basic facilities provided by Humerus include:
- A main menu screen, with buttons for the following
commands: About, New Game, Restore Game, Resume Game, Save
Game, Quit.
- Code for saving and restoring the state of a game,
including user interface code for requesting filenames and displaying
error messages.
- Asking whether to save game progress before quitting or
starting a new game.
Level support includes:
- User interface and support code for choosing a set of
levels to play.
- A Restart Level menu command.
- Automatically advancing through levels and recording the current level in saved games.
Level editor support facilities include:
- A level editor menu screen, with buttons for the following
commands: Create Level Set, New Level, Open Level, Save Level, Save
Level As, Test Level, Exit Editor.
- User interface and framework code for creating, loading and
saving level files and managing level sets.
- Asking whether to save changes to a level before quitting
or loading a different level.
Class Overview
The basic functionality of Humerus is provided by the following classes.
- Options
- This class defines certain standard command-line options
used by Humerus and provides code to parse and handle them. By
subclassing it, you can provide default values for the options, choose
which of them are to be changeable by the player, and add options of
your own.
-
HGame
-
A Humerus game contains one HGame instance. This object serves as a
central junction between the user interface and the internal state of
the game. You will typically subclass this class or one of its variations and add your own
game-specific state and functionality.
-
HShell
- This is a subclass of the Albow Shell class that implements the
default user interface functionality. You will typically subclass this class or one of its variations
and add game-specific user interface code.
- MainCommandScreen
- This class implements the default main menu. You can use it as-is, or
subclass it to customize and extend the menu.
You can also use it as a base class for other screens, such as your
playing screen, that don't have a menu but need to respond to the
keyboard equivalents of the menu commands.
Level functionality is provided by the following classes.
- HLGame
- Games that have levels should use this instead of HGame.
- HLShell
- Games that have levels should use this instead of HShell.
Level editor functionality is provided by the following classes.
- HEGame
- Games having a level editor should use this instead of HGame.
- HEShell
- Games having a level editor should use this instead of HShell.
-
EditCommandScreen
- This class implements the default level editor menu.
You can use it as-is, or
subclass it to customize and extend the menu.
You can also use it as a base class for other screens, such as your
level editor screen, that don't have a menu but need to respond to the
keyboard equivalents of the menu commands.
Structure
The following diagrams illustrate how the various classes of a Humerus game fit together.
Without levels
With levels but without level editor
With level editor
Usage
Creating a basic game
Using Humerus typically involves the following steps.
- Define
a subclass of Options that specifies the command-line options you want
to use. Before importing any other modules or instantiating any other
classes, it is recommended to instantiate your Options class. This will
process the command-line options and initialize the PyGame display.
Ensuring that the display is initialized will enable you to use Albow's
resource-loading facilities in the course of importing and defining
your other classes. For example,
from humerus.options import Options
class MyOptions(Options):
...
my_options = MyOptions()
If
you are making any changes to the default Albow or Humerus themes, you
should do this next, before instantiating any user interface classes.
- Define a subclass of HGame and instantiate it.
from humerus.hgame import HGame
class MyGame(HGame):
...
my_game = MyGame()
- Define
a subclass of HShell (or HEShell if your game will have a level editor)
and instantiate it, passing it your game and options objects.
from humerus.hshell import HShell
class MyShell(HShell):
...
my_shell = MyShell(my_game, my_options)
During initialization of your Shell object, you will probably want to create and attach whatever Screens you use.
- Call the run() method of your Shell object.
my_shell.run()
Creating a game with levels
The
above examples assume that your game doesn't have levels. If you want
support for levels, use HLShell and HLGame in place of HShell and
HGame. For example,
from humerus.options import Options
class MyOptions(Options):
...
my_options = MyOptions()
from humerus.hlgame import HLGame
from humerus.hlshell import HLShell
class MyGame(HLGame):
...
class MyShell(HLShell):
...
my_game = MyGame()
my_shell = MyShell(my_game, my_options)
Creating a game with a level editor
If
you want support for a level editor, use HEShell and HEGame in place of
HShell and HGame. There also one other thing to change: when creating
your Options object, pass with_editor = True to enable the editor-related command line options. For example,
from humerus.options import Options
class MyOptions(Options):
...
my_options = MyOptions(with_editor = True)
from humerus.hegame import HEGame
from humerus.heshell import HEShell
class MyGame(HEGame):
...
class MyShell(HEShell):
...
my_game = MyGame()
my_shell = MyShell(my_game, my_options)
Themes
Humerus
defines Albow themes for the following classes. You can redefine them
to customize the appearance of the standard menu screens.
Class Name | Base Class | Usage |
MainMenuTitle | Label | Title of the main menu screen |
MainMenuButton | Button | Buttons of the main menu screen |
EditMenuTitle | Label | Title of the editor menu screen |
EditMenuButton | Button | Buttons of the editor menu screen |
ChangeDot | Widget | Change indicator for level editor |
Example Code
There are three example programs in the examples/Pong directory:
pong.py - A very simple game exercising the basic functions of Humerus.
ponglev.py - An extended version with levels.
ponged.py - An extended version incorporating a level editor.
---
